Hyundai Santa Fe: Front Suspension System / Components and components location
Hyundai Santa Fe (TM) 2019-2025 Service Manual / Suspension System / Front Suspension System / Components and components location
| Components Location |
| 1. Front sub
frame 2. Drive shaft 3. Steering gear box |
4. Front stabilizer
bar 5. Front lower arm 6. Front knuckle assembly |
Front Strut Assembly. Components and components location
Components
1. Strut assembly
2. Spring lower pad
3. Dust cover
4. Coil spring
5. Spring upper pad
6. Bumper rubber
7...
