Hyundai Santa Fe (TM) 2019-2024 Owner's Manual / Emergency situations / If you have a flat tire (with spare tire) / Jack label

The actual Jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack.

1. Model Name

2. Maximum allowable load

3. When using the jack, set your parking brake.

4. When using the jack, stop the engine.

5. Do not get under a vehicle that is supported by a jack.

6. The designated locations under the frame

7. When supporting the vehicle, the base plate of jack must be vertical under the lifting point.

8. Shift into Reverse gear on vehicles with manual transmission or shift the gear to the P position on vehicles with automatic transmission.

9. The jack should be used on firm level ground.

10. Jack manufacture

11. Production date

12. Representative company and address
